| الاسم التجاري: | Casun |
| رقم الموديل: | 42SHD4425-24BSH |
| موك: | 5 قطعة |
| سعر: | $5.36~$6.92 |
| شروط الدفع: | د/أ، تي/تي، خطاب الاعتماد، د/ف |
| القدرة على العرض: | 10000 + جهاز كمبيوتر شخصى + شهر |
Nema 17 42*48mm 590mN.m Hybrid Stepper Motor 1.8° Degree 3.0V Casun Stepping Motor for 3D Printer
A high-performance Nema 17 stepper motor (42×48mm) delivering 590mN.m holding torque at 3.0V, optimized for 3D printers, CNC machines, and automation. With a 1.8° step angle, it ensures smooth, precise movements for consistent results.
Features:
|
Step Angel
|
1.8° |
|
Frame Size
|
48 mm |
|
Number of Phase
|
2 Phase |
|
Rated Current
|
2 Amp |
|
Holding Torque
|
590 mN.m |
|
Resistance
|
1.5 ohm |
|
Inductance
|
3 mH |
|
Rotor Inertia
|
82 g.cm² |
|
Motor weight
|
0.42 kg |
|
Connection
|
Bipolar |
Motor
Step Angle: 1.8°
Maximum Temperature: 80°C maximum
Ambient Temperature: -20 °C to 50°C
Storage Temperature -20: °C to 100°C
Humidity Range: 85% or less, non-condensing
Magnet Wire Insulation: Class B 130 deg C
Insulation Resistance: 100M Ohm at 500 VDC
Dielectric Strength: 500 VDC for 1 min
Encoder
Voltage: 5 v
Output: A + A - B + B - Z + Z -
Download
