| الاسم التجاري: | Casun |
| رقم الموديل: | B20SHD4351-86TP |
| موك: | 5 قطعة |
| سعر: | $27.89~$30 |
| شروط الدفع: | د/أ، تي/تي، خطاب الاعتماد، د/ف |
| القدرة على العرض: | 10000 + جهاز كمبيوتر شخصى + شهر |
Casun Nema 8 Stepper Motor with Dual Shaft 14mN.m High Precision 0.5Amp 2.75V Stepping Motor
A high-precision Nema 8 stepper motor (20×20 mm) featuring a dual shaft design for versatile mounting. Delivers 14 mN.m holding torque at just 0.5A/phase and 2.75 V, ensuring efficient low-power operation. Ideal for small robotics, lab equipment, and precision automation where space and accuracy matter.
Features:
|
Step Angel
|
1.8° |
|
Frame Size
|
28 mm |
|
Number of Phase
|
2 Phase |
|
Rated Current
|
0.5 Amp |
|
Holding Torque
|
14 mN.m |
|
Resistance
|
5.5 ohm |
|
Inductance
|
1.5 mH |
|
Rotor Inertia
|
2.7 g.cm² |
|
Motor weight
|
0.15 kg |
|
Connection
|
Bipolar |
Motor
Step Angle: 1.8°
Maximum Temperature: 80°C maximum
Ambient Temperature: -20 °C to 50°C
Storage Temperature -20: °C to 100°C
Humidity Range: 85% or less, non-condensing
Magnet Wire Insulation: Class B 130 deg C
Insulation Resistance: 100M Ohm at 500 VDC
Dielectric Strength: 500 VDC for 1 min
Encoder
Voltage: 5 v
Output: A + A - B + B - Z + Z -
