| الاسم التجاري: | Casun |
| رقم الموديل: | 57BL52R63-2460-25P |
| موك: | 1 قطعة |
| سعر: | $18-$28 |
| شروط الدفع: | د/أ، تي/تي، خطاب الاعتماد، د/ف |
| القدرة على العرض: | 40000+قطعة+شهر |
Brushless Motor Nema23 6000rpm 0.3N.M 63w DC Electric Motors
Type: BLDC (Brushless DC)
BLDC motors are electric motors that use a permanent magnet rotor and electronically commutated stator winding to generate motion. They offer advantages such as higher efficiency, longer lifespan, and better controllability compared to brushed DC motors.
NEMA23: NEMA (National Electrical Manufacturers Association) is a standard rating for motor frame sizes. NEMA23 refers to a specific motor size with a faceplate dimension of approximately 2.3 inches by 2.3 inches.
Max Speed: 6000 rpm (revolutions per minute)
This indicates the maximum rotational speed the motor can achieve under ideal conditions. It suggests that the motor can rotate at a maximum speed of 6000 revolutions per minute.
DC Voltage: 24V
This specifies the operating voltage required for the motor. In this case, the motor is designed to operate on a DC power supply of 24 volts.
Power Rating: 500W (watts)
This indicates the power rating or electrical output of the motor. It suggests that the motor can deliver a maximum power of 500 watts.
Max Torque: 0.3 N.m (Newton meters)
This represents the maximum torque output of the motor, which is a measure of rotational force. In this case, the motor can generate a maximum torque of 0.3 Newton meters.
Features:
|
Fram Size
|
57 mm |
|
Rated Current
|
9 A |
|
MaTorque
|
0.3N.m |
|
Resistance
|
6000rpm |
|
Inductance
|
6500rpm |
|
Rate Power
|
63 W |
|
Rate Voltage
|
24 V |
|
Number of poles
|
4 |
|
Insulation Class
|
Class B |
