| الاسم التجاري: | Casun |
| رقم الموديل: | 28SHD4401-20B |
| موك: | 1 قطعة |
| سعر: | $6.49-$9.5 |
| شروط الدفع: | د/أ، تي/تي، خطاب الاعتماد، د/ف |
| القدرة على العرض: | 40000+قطعة+شهر |
Hot Sale Micro NEMA 11 Stepper Motor 0.67A Stepping Motors 2 Phase Wiring For Revolving Light
28*28*44mm 0.67A 4.56V 2 Phase Wiring 1.8 Degree Stepper Motor Nema 11 Micro Stepping Motor
The 28mm Hybrid Stepper Motor Series offers powerful holding torque in a variety of sizes.
Use with a microstepping driver to reduce vibration and achieve higher step resolution.
Choose a baseline version or request your own customized configuration.
Features:
Appearance
Step Angel |
1.8 ° |
Fram Size |
28 mm |
Number of Phase |
2 Phase |
Rated Current |
0.6 7A |
Holding Torque |
95 mN.m |
Resistance |
6.8 ohm |
Inductance |
4.9 mH |
Rotor Inertia |
9 g-cm² |
Motor weight |
0.16 kg |
Number of leads |
4 |
Connection |
Bipolar |
