| الاسم التجاري: | Casun |
| رقم الموديل: | S2841114111-C27L |
| موك: | 1 قطعة |
| سعر: | $18-$23 |
| شروط الدفع: | د/أ، تي/تي، خطاب الاعتماد، د/ف |
| القدرة على العرض: | 40000+قطعة+شهر |
NEMA17 E42 Serious Multi-Sport Motor 200mN.M Multilayer Motor Fot Automation Equipment
nema11hybrid stepper motor 28X28X50mm 55mN.m Linear Multisport motor
The Nema17 stepper motor you described has the following specifications:
Step angle: 1.8 degrees per step
Size: 28 x 28 x 50 mm
Holding torque: 55 mN.m (milliNewton meter)
Type: Linear Multisport motor
A stepper motor is a type of electric motor that converts digital pulses into precise mechanical movements. Hybrid stepper motors are a type of stepper motor that combines the best features of both permanent magnet and variable reluctance motors. They have high torque, precision, and are commonly used in applications that require accurate positioning such as robotics, 3D printing, and CNC machines.
The holding torque of a stepper motor is the amount of torque required to stop the motor from rotating when it is energized. In this case, the NEMA 11 hybrid stepper motor has a holding torque of 55 mN.m, which indicates that it can generate a considerable amount of force to resist external loads.
Motor Specifications
Step Angel |
1.8 ° |
Fram Size |
28mm |
Number of Phase |
2 Phase |
Rated Current |
0.67A |
Holding Torque |
55mN.m |
Resistance |
30ohm |
Inductance |
45mH |
Rotor Inertia |
20 g-cm² |
Motor weight |
0.3kg |
Number of leads |
4 |
Connection |
Bipolar |
Appearance
