| الاسم التجاري: | CASUN |
| رقم الموديل: | 20SHD0255-15B2 |
| موك: | 1 قطعة-10 قطعة |
| سعر: | US $6.94 - 11.00/ Piece |
| شروط الدفع: | خطاب الاعتماد، د/أ، تي/تي |
| القدرة على العرض: | 100000pcs / شهر |
7.5V Motor Paso A Paso D Cut Shaft 15mm Nema 8 Stepper Motor 40mN.M For Office Automation
Micro 5.4V 2 Phase 0.6A Bipolar Nema 8 Stepper Motor for Robotics, 20*20*38mm.
Robotic Stepper Motor, 20x20x38mm, 32mN.m. Nema 8 2-phase, 4-wiring, 5.4-volt
Appearance
Step Angel |
1.8 ° |
Fram Size |
20 mm |
Number of Phase |
2 Phase |
Rated Current |
0.6 A |
Holding Torque |
40 mN.m |
Resistance |
12.5 ohm |
Inductance |
5.5 mH |
Rotor Inertia |
3.8 g-cm² |
Motor weight |
0.08 kg |
Number of leads |
4 |
Connection |
Leading |
If your needs can't be met by our regular motor.
We may modify the motor to meet your demands.
Special shafts, winding parameters, installation measurements, lead wires with unique specifications, connections, etc. are only a few examples of customized content.
FAQ
1. who are we?
We are based in Guangdong, China, start from 2011,sell to Domestic Market(63.00%),Western Europe(12.00%),North America(9.00%),Eastern Asia(8.00%),Northern Europe(2.00%),Eastern Europe(00.00%),Southeast Asia(00.00%),Oceania(00.00%),Mid East(00.00%),Southern Europe(00.00%),South Asia(00.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Stepper Motor,BLDC Motor
4. why should you buy from us not from other suppliers?
We are specialized in producing and selling stepper motors for more than 11 years.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,Express Delivery；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,,PayPal;
Language Spoken:English,Chinese,Japanese
