| الاسم التجاري: | Casun |
| رقم الموديل: | 57SHD4228-21H |
| موك: | 1 قطعة |
| سعر: | $21.54-$24.94 |
| شروط الدفع: | د/أ، تي/تي، خطاب الاعتماد، د/ف |
| القدرة على العرض: | 40000+قطعة+شهر |
Casun Stepper Motor NEMA 23 Open Loop Motor 1.1Nm Waterproof Stepper Motor
The Nema23 57MMX57MM Hybrid Open Loop Stepper Motor is a powerful and reliable option for anyone looking for a stepper motor solution for their CNC or SMT machine.
However, users should be aware that the open-loop design may be less precise than the closed-loop version, so it may not be suitable for all applications.
Features:
|
Step Angel
|
1.8 ° |
|
Fram Size
|
57 mm |
|
Number of Phase
|
2 Phase |
|
Rated Current
|
2.5 Amp |
|
Holding Torque
|
1.1N.m |
|
Resistance
|
1.15hm |
|
Inductance
|
3.3mH |
|
Rotor Inertia
|
220g-cm² |
|
Motor weight
|
0.6 2kg |
|
|
|
|
|
|
Motor
Step Angle: 1.8°
Maximum Temperature :80°C maximum
Ambient Temperature: -20 °C to 50°C
Storage Temperature -20: °C to 100°C
Humidity Range (%) :85% or less, non-condensing
Magnet Wire Insulation :Class B 130 deg C
Insulation Resistance :100M Ohm at 500 VDC
Dielectric Strength :500 VDC for 1 min
| Model | Holding Torque | Step Angle | Length | Type of Shaft | Rated Current |
| 42SHD4950 | 0.13N.m | 1.8° | 20mm | D Shaft-20mm | 1.0A |
| 42SHD4003 | 0.26N.m | 1.8° | 34mm | D Shaft-20mm | 0.4A |
| 42SHD0261 | 0.45N.m | 1.8° | 40mm | D Shaft-20mm | 1.68A |
| 42SHD4425 | 0.59N.m | 1.8° | 48mm | D Shaft-24mm | 2.0A |
| 42SHD4813 | 0.8N.m | 1.8° | 60mm | D Shaft-24mm | 2.1A |
Download
We have the ability to customize motor features such as shafts, winding parameters, installation dimensions, lead wires, and connectors can help to ensure that the motor is a perfect fit for the customer's application. This can lead to improved efficiency, increased reliability, and reduced downtime.
