2 Phase 1.8 Degree Hollow Shaft NEMA 11 Micro Stepper Motor for Medical Machine Robot Camera
The 28mm Hybrid Stepper Motor Series offers powerful holding torque in a variety of sizes.
Use with a microstepping driver to reduce vibration and achieve higher step resolution.
Choose a baseline version or request your own customized configuration.
Features:
Appearance
Step Angel |
1.8 ° |
Fram Size |
28 mm |
Number of Phase |
2 Phase |
Rated Current |
0.67 A |
Holding Torque |
120 mN.m |
Resistance |
9.5 ohm |
Inductance |
6.8 mH |
Rotor Inertia |
18 g-cm² |
Motor weight |
0.2 kg |
Number of leads |
4 |
Connection |
Bipolar |
