20x20mm 0.24A 5.04V 10mNM Nema 8 Hybrid Stepper Motor For DIY 3D Silver

20x20mm 0.24A 5.04V 10mNM Nema 8 Hybrid Stepper Motor For DIY 3D Silver

الاسم التجاري:	Casun
رقم الموديل:	B20SHD4701-14P
موك:	1 قطعة
شروط الدفع:	د/أ، تي/تي، خطاب الاعتماد، د/ف
القدرة على العرض:	40000+قطعة+شهر

معلومات مفصلة

وصف المنتج

معلومات مفصلة

مكان المنشأ:

الصين

إصدار الشهادات:

CE,ROSH,ISO

خطوة الملاك:

1.8 درجة

عقد عزم الدوران:

10mN.m

حاضِر:

0.24 أ

طول المحرك:

24.8mm

رمح:

عمود دائري بطول 14 ملم

حسب الطلب:

يمكن تصميم المحرك وتصنيعه حسب الطلب.

تفاصيل التغليف:

الكرتون: 36 × 29 × 14 سم

إبراز:

20x20mm Hybrid Stepper Motor,0.24A 5.04V Nema 8 Stepper Motor,10mNM Nema 8 Stepper Motor

0.24A 5.04V Nema 8 Stepper Motor

10mNM Nema 8 Stepper Motor

وصف المنتج

20x20x33mm 0.6A Casun Stepper Motor Nema 8 Mini Stepper Motor For Medical beauty equipment

Motor Specifications

Step Angel	1.8 °
Fram Size	20 mm
Number of Phase	2 Phase
Rated Current	0.24 A
Holding Torque	10 mN.m
Resistance	3.8 ohm
Inductance	21mH
Rotor Inertia	2g-cm²
Motor weight	0.08 kg
Number of leads	4
Connection	Bipolar

Appearance

Dimensions

Torque Curves

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get a quote" button below to tell us your requirements.
