35x35mm 155mN.M Nema 14 Hybrid Stepper Motor For Beauty Equipment 1A 3.8V

35x35mm 155mN.M Nema 14 Hybrid Stepper Motor For Beauty Equipment 1A 3.8V

الاسم التجاري:	Casun
رقم الموديل:	35SHD4103-10B
موك:	1 قطعة
سعر:	$4.2-$5.2
شروط الدفع:	د/أ، تي/تي، خطاب الاعتماد، د/ف
القدرة على العرض:	40000+قطعة+شهر

معلومات مفصلة

وصف المنتج

معلومات مفصلة

مكان المنشأ:

الصين

إصدار الشهادات:

CE,ROSH,ISO

خطوة الملاك:

1.8 درجة

عقد عزم الدوران:

155 م.ن.م

حاضِر:

1 أ

طول المحرك:

34 مللي متر

رمح:

عمود دائري بطول 10 ملم

حسب الطلب:

يمكن تصميم المحرك وتصنيعه حسب الطلب.

تفاصيل التغليف:

الكرتون: 36 × 29 × 14 سم

إبراز:

35x35mm 155mN.M Nema 14,Nema 14 Hybrid Stepper Motor,1A 3.8V Nema 14 Stepper Motor

Nema 14 Hybrid Stepper Motor

1A 3.8V Nema 14 Stepper Motor

وصف المنتج

Nema 14 Hybrid stepper motor 35x35mm 1A 3.8V 155mN.m for beauty equipment

20x20x33mm 0.6A Casun Stepper Motor Nema 8 Mini Stepper Motor For Medical beauty equipment

Motor Specifications

Step Angel	1.8 °
Fram Size	35 mm
Number of Phase	2 Phase
Rated Current	1 A
Holding Torque	155 mN.m
Resistance	3.8 ohm
Inductance	5.8mH
Rotor Inertia	14 g-cm²
Motor weight	0.18 kg
Number of leads	4
Connection	Bipolar

Appearance

Dimensions

Torque Curves

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get a quote" button below to tell us your requirements.

العلامات:

2 Phase Bipolar Stepper Motor,Nema 6 Bipolar Stepper Motor

35x35mm 155mN.M Nema 14,Nema 14 Hybrid Stepper Motor,1A 3.8V Nema 14 Stepper Motor

35x35mm 155mN.M Nema 14
