| الاسم التجاري: | Casun |
| رقم الموديل: | 46SHY4401-2A1 |
| موك: | 1 قطعة |
| سعر: | $13.8-15.38 |
| شروط الدفع: | د/أ، تي/تي، خطاب الاعتماد، د/ف |
| القدرة على العرض: | 40000+قطعة+شهر |
If our basic motor does not satisfy your requirements, we may customise the motor to meet your specifications.
unique shafts, winding parameters, installation measurements, lead wires with unique needs, connections, and so forth are examples of customised content.
Features:
*Both bipolar and unipolar versions available.
*Stepper hybrid construction
*Available in single and double shaft configurations.
*Customizations on request are CE and RoHS approved.
|
Step Angel
|
1.8 ° |
|
Fram Size
|
46mm |
|
Number of Phase
|
2 Phase |
|
Rated Current
|
1.0Amp |
|
Holding Torque
|
52 mN.m |
|
Resistance
|
2.5 om |
|
Inductance
|
1.7mH |
|
Rotor Inertia
|
7 g-cm² |
|
Motor weight
|
0.1kg |
|
Number of leads
|
4 |
|
Connection
|
Bipolar |
Step Angle: 1.8°
Maximum Temperature :80°C maximum
Ambient Temperature: -20 °C to 50°C
Storage Temperature -20: °C to 100°C
Humidity Range (%) :85% or less, non-condensing
Magnet Wire Insulation :Class B 130 deg C
Insulation Resistance :100M Ohm at 500 VDC
Dielectric Strength :500 VDC for 1 min
| Model | Motor Length | Current | Holding Torque | |
| P28SHD4611 | 9.5mm | 0.5A | 16mN.m | |
| P28SHD4701 | 10.6mm | 0.5A | 20mN.m | |
| P28SHD4750 | 13-15mm | 0.5A | 25mN.m | |
| P28SHD4950 | 17.9mm | 0.5A | 35mN.m | |
