| الاسم التجاري: | Casun |
| رقم الموديل: | 35SHD0801-30B |
| موك: | 1 قطعة |
| سعر: | $4.14-$6.98 |
| شروط الدفع: | د/أ، تي/تي، خطاب الاعتماد، د/ف |
| القدرة على العرض: | 40000+قطعة+شهر |
The operation of the 35mm stepper motor is relatively stable, without the potential vibration and resonance problems of traditional DC motors.
Water pumps, electronic door locks, image scanners, and fine positioning devices are examples of small automation systems.
Features:
Step Angel |
1.8 ° |
Fram Size |
35 mm |
Number of Phase |
2 Phase |
Rated Current |
0.5 A |
Holding Torque |
220 mN.m |
Resistance |
18 ohm |
Inductance |
25.5 mH |
Rotor Inertia |
18 g-cm² |
Motor weight |
0.21 kg |
Number of leads |
4 |
Connection |
Bipolar |
