350mNm 33 Ohm Stepper Motor 1.8 Step Angle Two Phase CE ISO ROHS

350mNm 33 Ohm Stepper Motor 1.8 Step Angle Two Phase CE ISO ROHS

الاسم التجاري:	Casun
رقم الموديل:	P35SHD0808-20B
موك:	1 قطعة
سعر:	$4.14-$6.98
شروط الدفع:	د/أ، تي/تي، خطاب الاعتماد، د/ف
القدرة على العرض:	40000+قطعة+شهر

معلومات مفصلة

وصف المنتج

معلومات مفصلة

مكان المنشأ:

الصين

إصدار الشهادات:

CE,ROHS,ISO

خطوة الملاك:

1.8 درجة

عقد عزم الدوران:

350mN.m

حاضِر:

0.4A

طول المحرك:

40 ملم

رمح:

طحن رمح مسطح بطول 20 مم

حسب الطلب:

يمكن تصميم المحرك وتصنيعه حسب الطلب.

تفاصيل التغليف:

الكرتون: 36 × 29 × 14 سم

إبراز:

33 ohm Stepper Motor 1.8 Step Angle,350mNm Stepper Motor,350mNm Two Phase Stepper Motor

350mNm Stepper Motor

350mNm Two Phase Stepper Motor

وصف المنتج

The 35mm stepper motor can rotate at a small step angle and accurately locate the desired position.

Small automation systems, water pumps, electric door locks, image scanners, and precision positioning tools

Features:

Within 48 hours, one of our engineers will contact you with the best option
Offer specialised services
Available in single or double shaft versions
Ten-year warranty and secure shopping
Customizations on request

Motor Specifications

Step Angel	1.8 °
Fram Size	35 mm
Number of Phase	2 Phase
Rated Current	0.4 A
Holding Torque	350 mN.m
Resistance	33 ohm
Inductance	42 mH
Rotor Inertia	12 g-cm²
Motor weight	0.15 kg
Number of leads	4
Connection	Bipolar

Appearance

Dimensions

Torque Curves

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get a quote" button below to tell us your requirements.
