0.5A Casun NEMA 14 Stepper Motor 40mm Body High Torque DC Motor

0.5A Casun NEMA 14 Stepper Motor 40mm Body High Torque DC Motor

الاسم التجاري:	Casun
رقم الموديل:	P35SHD0807-24B
موك:	1 قطعة
سعر:	$4.14-$6.98
شروط الدفع:	د/أ، تي/تي، خطاب الاعتماد، د/ف
القدرة على العرض:	40000+قطعة+شهر

معلومات مفصلة

وصف المنتج

معلومات مفصلة

مكان المنشأ:

الصين

إصدار الشهادات:

CE,ROHS,ISO

خطوة الملاك:

1.8 درجة

عقد عزم الدوران:

180mN.m

حاضِر:

0.5 أ

طول المحرك:

40 ملم

رمح:

طحن رمح مسطح بطول 24 مم

حسب الطلب:

يمكن تصميم المحرك وتصنيعه حسب الطلب.

تفاصيل التغليف:

الكرتون: 36 × 29 × 14 سم

إبراز:

0.5A Casun NEMA 14 Stepper Motor,Casun NEMA 14 Stepper Motor 40mm,Casun High Torque DC Motor

Casun NEMA 14 Stepper Motor 40mm

Casun High Torque DC Motor

وصف المنتج

The 35 step motor can quickly respond to control signals, achieving faster motion response speed.

By giving the correct pulse sequence, basic operations such as rotation and stop can be achieved.

Features:

Bipolar or unipolar versions available
Knowledgeable manufacturing and research
Available in single or double shaft versions
CE and RoHS approved
Each model of stepper motor can be suitable for different scenarios

Motor Specifications

Step Angel	1.8 °
Fram Size	35 mm
Number of Phase	2 Phase
Rated Current	0.5 A
Holding Torque	180 mN.m
Resistance	4.5 ohm
Inductance	5.8 mH
Rotor Inertia	35 g-cm²
Motor weight	0.3 kg
Number of leads	4
Connection	Bipolar

Appearance

Dimensions

Torque Curves

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get a quote" button below to tell us your requirements.
