| الاسم التجاري: | Casun |
| رقم الموديل: | B20SHD4252-10P |
| موك: | 1 قطعة |
| سعر: | $5.94-$8.6 |
| شروط الدفع: | د/أ، تي/تي، خطاب الاعتماد، د/ف |
| القدرة على العرض: | 40000+قطعة+شهر |
The 28mm base stepper motor can accurately control the position according to the predetermined step size, achieving high-precision positioning and motion control.
Make it very useful in many applications, such as printers, robots, automation equipment, etc.
Features:
Step Angel |
1.8 ° |
Fram Size |
20 mm |
Number of Phase |
2 Phase |
Rated Current |
0.6 A |
Holding Torque |
40 mN.m |
Resistance |
10 ohm |
Inductance |
4.5 mH |
Rotor Inertia |
4.5 g-cm² |
Motor weight |
0.1 kg |
Number of leads |
4 |
Connection |
Bipolar |
Appearance
