Mini 20mNm NEMA 8 Stepper Motor 0.6A Casun Stepper Motor For Beauty Equipment

Mini 20mNm NEMA 8 Stepper Motor 0.6A Casun Stepper Motor For Beauty Equipment

الاسم التجاري:	Casun
رقم الموديل:	20SHD0501-20
موك:	1 قطعة
سعر:	$5.94-$8.6
شروط الدفع:	د/أ، تي/تي، خطاب الاعتماد، د/ف
القدرة على العرض:	40000+قطعة+شهر

معلومات مفصلة

وصف المنتج

معلومات مفصلة

مكان المنشأ:

الصين

إصدار الشهادات:

CE,ROSH,ISO

خطوة الملاك:

1.8 درجة

عقد عزم الدوران:

20mN.m

حاضِر:

0.6 أ

طول المحرك:

33 ملم

رمح:

عمود دائري بطول 10 ملم

حسب الطلب:

يمكن تصميم المحرك وتصنيعه حسب الطلب.

تفاصيل التغليف:

الكرتون: 36 × 29 × 14 سم

إبراز:

0.6A Casun Stepper Motor,Mini 20mNm NEMA 8 Stepper Motor,Casun NEMA 8 Stepper Motor

Mini 20mNm NEMA 8 Stepper Motor

Casun NEMA 8 Stepper Motor

وصف المنتج

20x20x33mm 0.6A Casun Stepper Motor Nema 8 Mini Stepper Motor For Medical beauty equipment

Motor Specifications

Step Angel	1.8 °
Fram Size	20 mm
Number of Phase	2 Phase
Rated Current	0.6 A
Holding Torque	20 mN.m
Resistance	5.8 ohm
Inductance	1.5 mH
Rotor Inertia	2.5 g-cm²
Motor weight	0.07 kg
Number of leads	4
Connection	Bipolar

Appearance

Dimensions

Torque Curves

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Connector

Please click the "Get a quote" button below to tell us your requirements.
